HOW IS SPC FLOORING MADE?

Author: Site Editor     Publish Time: 2022-03-07      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

What is SPC flooring?

SPC flooring stands for Stone Plastic Composite flooring, is a high-tech research and development of new ground decorative materials, the use of natural marble powder to form a high-density of the solid base, the surface is covered with super-strong wear-resistant polymer PVC wear layer, after Hundreds of procedures to process and become. The product pattern is realistic and beautiful, super wear-resistant, the surface is bright and not slippery, which is a model of new high-tech materials in the 21st century!

What is SPC flooring made of?

Limestone (Calcium Carbonate)

PVC Resin Powder

DOTP(Plasticizer)

Stabilizer (Ca/Zn)

Stearine

Pulverizing material

PE wax / Carbon black

ACR / CPE

NOTICE: Based on the above formula of each manufacturer is slightly different.

The role of raw materials

The bottom material is often tough and not easy to break. It is composed of polyvinyl chloride, calcium powder, plasticizer, and other materials. The middle layer material is easier to break, so the bottom material and the middle layer material can stretch together to make the board Not easy to upturn.

PVC Resin Powder: PVC is a non-toxic, odorless white powder. It has high chemical stability and good plasticity. PVC is the most widely used and most important polymer in the world, but pure PVC is actually the most unstable polymer, so only after adding appropriate stabilizers and other additives, the advantages of PVC can be realized.

Carbon Black: the pigment with the strongest tinting power and hiding power, the most stable pigment, heat resistance, chemical resistance, and light resistance

Limestone Powder: insoluble in water and soluble in acid, function: increase opacity and improve flexibility.

DOTP (Plasticizer): It is a colorless, low-viscosity liquid. As PVC itself is a hard material, after adding a plasticizer, the plastic product can be soft, easy to bend, fold, and elastic, and easy to shape.

Stabilizer: It can slow down the reaction, maintain chemical balance, reduce surface tension, prevent light, thermal decomposition, or oxidation reactions, etc., thereby promoting product quality stability.

Main equipment to produce SPC flooring

Mixing and Heating Line

Extruding Line

Hot Pressing Line

SPC Production Line

UV Coating Line

Annealing Line

Multi-Blade Sawing Line

HOMAG Profiling Line

Painted Bevel Line

SPC flooring production process

Mixing materials

Put the PVC resin powder, plasticizer, stabilizer, and carbon black into the mixer according to the formula ratio, and the machine automatically adds the plasticizer. add limestone powder, stir for about 30 minutes, and send the evenly mixed mixture to the conveyor belt and enter the internal mixer for heating and mixing.

Extruding blocks

The raw material powder enters the roller, and gradually forms after being rolled by the roller. The temperature is about 170°C. Finally, the raw material is cooled and refined, will be produced into the middle base layer and bottom base layer through the dense refining, and the raw material is cut into 1*1m or 1*1.3m blocks.

Film laying

Spread canvas, embossed board, soft film (matt film, high-temperature paper), bottom/middle material, wear-resistant layer, color film, and soft film (matt film, high-temperature paper) on the steel plate in sequence.

Hot pressing

After being pressed with another steel plate, it is sent to the hot press, continuously heated and pressurized, and taken out after about 40 minutes. After the soft film is torn off, the floor is pressed into shape. After hot pressing, the product layer is firmly bonded to the layer.

UV coating

Put the pressed whole floor into the conveyor belt, apply a layer of UV paint uniformly by the roller, and then receive ultraviolet radiation and enter the oven for baking.

In this process, the UV paint will be applied twice, and the ultraviolet radiation will be applied twice. The purpose of UV paint is to increase the gloss to meet customer requirements (the brightness of the floor is not directly related to the amount of UV paint, mainly controlled by the brightness of the UV paint).

Annealing

After the paint is fully cured, the floor is sent to cold water to cool. Finally, use a cooler to dry the water on the surface. Finally, put it into the normal temperature and normal state of being.

The purpose of tempering is to strengthen the shrinkage and warpage of the PVC floor through heating and cooling on the assembly line.

Shaped the floor

The floor is heated by the machine to make it easier to punch. Forming different shapes.

Profiling

Profiling is carried out according to customer requirements. Adjusted by the knife adjuster according to the size of the floor. After adjustment, put the pieces of the floor on the conveyor belt, first profiling the long side, then the short side.

Profiling machine guarantees the high accuracy of click products.

Groove engraving of the floor

After engraving the groove, the texture of the product imitating wood/stone/carpet texture is more realistic.

Package

The floor inspects and does the final cleaning before entering the box. In particular, it is necessary to remove obvious scratches, impurities, dirt, bubbles, color difference, discoloration, white edges, delamination, folding, bevel, residual angle, etc. failed products. Finally seals the box, check the label, and mark content accurately.
