More and more people choose SPC flooring to decorate the ground. Choosing the right color flooring for your home or project can seem daunting. Some people prefer darker colors and some prefer lighter ones. Some people prefer a smooth surface and others prefer an embossed texture that matches real wo
When it comes to this question, I think most people have known the answer. They are three main factors: Quality, Price, Service. Why i put the quality as the first position is that a good quality product is always the base of any commercial cooperation. It is like a building, if the foundation was n
Cutting the planks is super easy – you don’t even need any fancy tools. In order to cut your rigid core planks for installation, just follow these simple steps: Mark the measurement then use a utility knife and straight edge to score the plank.Turn the plank over and bend it back along the cut. Use
SPC Flooring is an upgrade of Luxury Vinyl Tiles (LVT), it's special designed with Click-Locking joint system, easy installation, water-proof, the basic material is Stone-Plastic composite, it's formaldehyde free, completely safe flooring covering materials for both residential and public environmen
PTW6026-3
Protex
SKU: | |
---|---|
Availability: | |
Description | WPC VINYL FLOORING |
Construction | WPC core(Wood Powder+Virgin PVC composite,not contain plasticizer) |
Finish | BP/Handscrap/Marble/ Deep embossed/EIR |
Wear Layer | 0.3mm/0.5mm/0.7mm wear-layer for residential,light commercial&heavy commercial |
Gloss Level | 5%-7% |
Profile | Angle installation,Drop and Lock |
Edge | Square edge,Micro-bevel, V Groove with painted |
Installation | Valinge,Unilin,I4F click system,Glue free |
Available plank size | 12''x12'',12''x24'',6''x36'', 7''x48'', 9''x48'', 9''x60'' |
Usage | Kitchen room, Bathroom, Homes, Schools,Hospital, Malls, Pubs and any indoor areas |
Warranty | 10 years for commercial and 20 years for residential |
Description | WPC VINYL FLOORING |
Construction | WPC core(Wood Powder+Virgin PVC composite,not contain plasticizer) |
Finish | BP/Handscrap/Marble/ Deep embossed/EIR |
Wear Layer | 0.3mm/0.5mm/0.7mm wear-layer for residential,light commercial&heavy commercial |
Gloss Level | 5%-7% |
Profile | Angle installation,Drop and Lock |
Edge | Square edge,Micro-bevel, V Groove with painted |
Installation | Valinge,Unilin,I4F click system,Glue free |
Available plank size | 12''x12'',12''x24'',6''x36'', 7''x48'', 9''x48'', 9''x60'' |
Usage | Kitchen room, Bathroom, Homes, Schools,Hospital, Malls, Pubs and any indoor areas |
Warranty | 10 years for commercial and 20 years for residential |
![]() wpc flooring | ![]() wpc flooring | ![]() wpc flooring |
![]() wpc flooring | ![]() wpc flooring | ![]() wpc flooring |
No | Characteristic | Technology Target | Remark | |||||
1 | Appearance | No chipping, cracking, visual texture ,delamination, bubbles, shallow embossing, scratches, dirt, poor cut, etc | ENEN649 | |||||
2 | Size mm(23℃) | Length | ± 0.20mm | EN427 | ||||
Wide | ± 0.10mm | EN427 | ||||||
Thickness | +0.13mm, -0.10mm | EN428 | ||||||
Thickness Range | ≤0.15 mm | EN428 | ||||||
wearlay Thickness | ± 0.02 mm | EN429 | ||||||
3 | Squareness mm | ≤ 0.15 | EN427 | |||||
4 | Crook mm | ≤ 0.15 | EN427 | |||||
5 | Microbevel Cut Angle | 8-15 degrees | ||||||
Microbevel Cut Depth | 0.60 – 1.5 mm | |||||||
6 | Dimensional stability after exposure to heat | ≤ 0.12% | EN434 | |||||
7 | Curling after exposure to heat | WPC:≤0.2(70℃/6Hr) SPC:≤0.2(80℃/6Hr) | EN434 | |||||
8 | Gloss level | nominal value ± 1.5 | Lightmeter | |||||
9 | Taber Abrasion - Minimum | 0.5mm wear lay | ≥5000 cycles Average | EN660 | ||||
10 | Uv | 8~12g/m2 | ||||||
11 | ≥9N | |||||||
SCRATCH PERFORMANCE UV | SCLEROMETER | |||||||
12 | Anti-stain performance | Iodine | 3 | Modified ASTM 92 | ||||
Oil Brown | 0 | |||||||
Mustard | 0 | |||||||
Shope Polish | 2 | |||||||
Blue Sharpie | 1 | |||||||
13 | Determination of flexibility | no crack | EN435 | |||||
14 | Peel Resistance | Length | ≥62.5N/5cm | EN431(62.5N/5cm,100mm/s) | ||||
width | ≥62.5N/5cm | |||||||
15 | Residual indentation (average) mm | ≤0.15 | EN433 | |||||
16 | Color fastness: | ≥7 | ISO105-B2:2002 | |||||
17 | Locking Strength | fsmax ≥2 .5N/mm | ISO24344 |
No | Characteristic | Technology Target | Remark | |||||
1 | Appearance | No chipping, cracking, visual texture ,delamination, bubbles, shallow embossing, scratches, dirt, poor cut, etc | ENEN649 | |||||
2 | Size mm(23℃) | Length | ± 0.20mm | EN427 | ||||
Wide | ± 0.10mm | EN427 | ||||||
Thickness | +0.13mm, -0.10mm | EN428 | ||||||
Thickness Range | ≤0.15 mm | EN428 | ||||||
wearlay Thickness | ± 0.02 mm | EN429 | ||||||
3 | Squareness mm | ≤ 0.15 | EN427 | |||||
4 | Crook mm | ≤ 0.15 | EN427 | |||||
5 | Microbevel Cut Angle | 8-15 degrees | ||||||
Microbevel Cut Depth | 0.60 – 1.5 mm | |||||||
6 | Dimensional stability after exposure to heat | ≤ 0.12% | EN434 | |||||
7 | Curling after exposure to heat | WPC:≤0.2(70℃/6Hr) SPC:≤0.2(80℃/6Hr) | EN434 | |||||
8 | Gloss level | nominal value ± 1.5 | Lightmeter | |||||
9 | Taber Abrasion - Minimum | 0.5mm wear lay | ≥5000 cycles Average | EN660 | ||||
10 | Uv | 8~12g/m2 | ||||||
11 | ≥9N | |||||||
SCRATCH PERFORMANCE UV | SCLEROMETER | |||||||
12 | Anti-stain performance | Iodine | 3 | Modified ASTM 92 | ||||
Oil Brown | 0 | |||||||
Mustard | 0 | |||||||
Shope Polish | 2 | |||||||
Blue Sharpie | 1 | |||||||
13 | Determination of flexibility | no crack | EN435 | |||||
14 | Peel Resistance | Length | ≥62.5N/5cm | EN431(62.5N/5cm,100mm/s) | ||||
width | ≥62.5N/5cm | |||||||
15 | Residual indentation (average) mm | ≤0.15 | EN433 | |||||
16 | Color fastness: | ≥7 | ISO105-B2:2002 | |||||
17 | Locking Strength | fsmax ≥2 .5N/mm | ISO24344 |
