PTW6047-7 Erosion-proof Vinyl Wpc Panel Flooring

Construction:WPC core(Wood Powder+Virgin PVC composite,not contain plasticizer)
Finish:BP/Handscrap/Marble/ Deep embossed/EIR
Wear Layer:0.3mm/0.5mm/0.7mm wear-layer for residential,light commercial&heavy commercial
Gloss Level:5%-7%
Profile:Angle installation,Drop and Lock
Edge:Square edge,Micro-bevel, V Groove with painted
Installation:Valinge,Unilin,I4F click system,Glue free
Available plank size:12''x12'',12''x24'',6''x36'', 7''x48'', 9''x48'', 9''x60''
Usage:Kitchen room, Bathroom, Homes, Schools,Hospital, Malls, Pubs and any indoor areas
Warranty:10 years for commercial and 20 years for residential

Quantity:
  • PTW6047-7
  • Protex

Description

 WPC VINYL FLOORING

Construction

WPC core(Wood Powder+Virgin PVC composite,not contain plasticizer)

Finish

BP/Handscrap/Marble/ Deep embossed/EIR

Wear Layer

0.3mm/0.5mm/0.7mm wear-layer for residential,light commercial&heavy commercial

Gloss Level

5%-7%

Profile

Angle installation,Drop and Lock

Edge

Square edge,Micro-bevel, V Groove with painted

Installation

Valinge,Unilin,I4F click system,Glue free

Available plank size

12''x12'',12''x24'',6''x36'', 7''x48'', 9''x48'', 9''x60''

Usage

Kitchen room, Bathroom, Homes, Schools,Hospital, Malls, Pubs and any indoor areas

Warranty

10 years for commercial and 20 years for residential


wpc flooring

wpc flooring


wpc flooring

wpc flooring


wpc flooring

wpc flooring


How to discharge flooring

flooring discharge

How to engage flooring

flooring engage

engage flooring


No Characteristic Technology Target Remark
1Appearance No chipping, cracking, visual texture ,delamination, bubbles, shallow embossing, scratches, dirt, poor cut, etc                                                  ENEN649
2Size    尺寸      mm(23℃)Length   ± 0.20mmEN427
Wide   ± 0.10mmEN427
Thickness +0.13mm,  -0.10mmEN428
Thickness Range     ≤0.15 mmEN428
wearlay Thickness  ± 0.02 mmEN429
3Squareness       mm ≤ 0.15EN427
4Crook   mm ≤ 0.15EN427
5Microbevel Cut Angle   8-15 degrees
Microbevel Cut Depth 0.60 – 1.5 mm
6Dimensional stability after exposure to heat ≤ 0.12%EN434
7Curling after exposure to heat      WPC:≤0.2(70℃/6Hr)
SPC:≤0.2(80℃/6Hr)
EN434
8Gloss level   nominal value ± 1.5Lightmeter
9Taber Abrasion  - Minimum 0.5mm wear lay≥5000 cycles AverageEN660
10Uv8~12g/m2
11
≥9N
SCRATCH PERFORMANCE     UVSCLEROMETER
12Anti-stain performance Iodine3Modified ASTM 92
Oil Brown0
Mustard0
Shope Polish2
 Blue Sharpie1
13 Determination of flexibilityno crackEN435
14Peel Resistance Length≥62.5N/5cmEN431(62.5N/5cm,100mm/s)
width≥62.5N/5cm
15Residual indentation (average)  mm≤0.15EN433
16Color fastness: ≥7ISO105-B2:2002
17Locking Strength fsmax ≥2 .5N/mmISO24344
